EI 192 CRNGO EI Transformer Lamination Single Phase Crgo Transformer Lamination Core

Ask Lasest Price
Brand Name :	CENTERSKY or NO LOGO
Model Number :	EI 96, EI 114, EI 126, EI 133.2, EI 150, EI 152.4, EI 180,
Certification :	ISO, ROHS
Price :	1.0usd/kg
Payment Terms :	L/C, T/T, D/P
Supply Ability :	15000 MT Per Year
Delivery Time :	5-18 DAYS

Add to Cart

Product Details
Company Profile

EI 192 CRNGO EI Transformer Lamination Single Phase Crgo Transformer Lamination Core

EI 192 CRNGO Single Phase Ei Transformer Iron Core

Transformers are used to change AC voltage levels, such transformers being termed step-up or step-down type to increase or decrease voltage level, respectively. Transformers can also be used to provide galvanic isolation between circuits as well as to couple stages of signal-processing circuits. Since the invention of the first constant-potential transformer in 1885, transformers have become essential for the transmission, distribution, and utilization of alternating current electric power.A wide range of transformer designs is encountered in electronic and electric power applications. Transformers range in size from RF transformers less than a cubic centimeter in volume, to units weighing hundreds of tons used to interconnect the power grid.

Application:

Main application: auto transformers, control transformers, voltage stabilizers, line reactors, inductors, resistors and etc.

Introduction:
Single phase EI core is made by the silicon steel strip. The model of EI lamination in standard sizes is from

EI-30 to EI-360.The gap sizes of transformer lamination core can be customized.

Catalogue:

Type	a	b	c	d	e	holes	aperture
EI- 28	28	4	6	8	17
EI-35	35	5	7.5	10	19.5
EI-41	41	6	8	13	21
EI-42	42	7	7	7	14
EI-48	48	8	8	16	24
EI-50	50	8	9	16	25.5
EI-57	57	9.5	9.5	19	28.5	4	4
EI-60	60	10	10	20	30	4	5
EI-66	66	11	11	22	33	4	4
EI-75	75	12.5	12.5	25	37.5	4	5.5
EI-76.2	76.2	12.7	12.7	25.4	38.1	4	5
EI-78	78	13	13	26	39	4	5
EI-84	84	14	14	28	41	4	6
EI-85.8	85.8	14.3	14.3	28.6	42.9	4	5
EI-96	96	16	16	32	48	4	6
EI-105	105	17.5	17.5	35	52.5	4	6
EI-108	108	18	18	36	54	4	5.5
EI-114	114	19	19	38	57	4	6
EI-120	120	20	20	40	60	4	7
EI-126	126	21	21	42	63	4	7
EI-133.2	133.2	22.2	22.2	44.4	66.6	4	7
EI-150	150	25	25	50	75	4	8
EI-152.4	152.4	25.4	25.4	50.8	76.2	4	8
EI-162	162	27	27	54	81	4	10
EI-168	168	28	28	50	84	4	10
EI-171	171	28.5	28.5	57	85.5	4	10
EI-180	180	30	30	60	90	4	10
EI-190.5	190.5	31.75	31.75	63.5	95.25	4	10
EI-192	192	32	32	64	96	4	10
EI-210	210	35	35	70	105	4	10
EI-228	228	38	38	76	114	4	10
EI-240	240	40	40	80	120	4	10
EI-254	254	48	55	48	164	4	12
EI-270	270	45	45	90	135	4	12
EI-228	228	38	38	76	114	4	10
EI-300	300	50	50	100	150	4	12
EI-360	360	60	60	120	180	4	12

Company information:

Jiangyin Centersky was established in 2000. Main business is manufacturing silicon steel EI lamination, UI lamination, cutting lamination.

Our capacity is 15000mt per year. We have 15 years' export experience.

Worlshop:

FAQ:

1. Q: Can I get some samples?

A: Yes, sample order is available for quality checking and market test.

1-10kg of sample is free.

2. Q: What's the delivery time?

A: Sample order needs 2-3 days. Formal order needs 8-15 days.

3. Q: What's your payment terms?

A: We usually accept T/T at sight as the main payment terms, and other payment can also be negotiated.

4. Q: Do you have the prodcts in stock?

A: Yes, we will keep some general ones in stock.

5. Q: Can I mix different models in one container?

A: Yes, different models can be mixed up.
